Description
SPECIFICATION
Type Single Phase
Maximum Output(W) 5500
Rated Output(W) 5000
Rated Voltage(V) 230/115
Rated Frequency(Hz) 50
Rated current(A) 21.7
DC Rated Output N/A
Engine Model i-GX390
Engine Type 4 Stroke, OHV, 1 cylinder
Displacement(cm3)
389
Bore x Stroke(mm) 88.0×64.0
Engine Speed(rpm) 3,000 max
Cooling System Forced Air
Ignition System Transistor
Oil Capacity(L) 1.10
Fuel Tank Capacity(L) 23.5
Operating Time at Rated 8h
Starter System Recoil and Electric Start
Length(mm) Handle Down: 725
Handle Up: 1,047.5
Width(mm) 706
Height(mm) 719
Dry Weight(kg) 108.8
Sound Pressure Level at Workstation – dB(A)
(98/37/EC, 2006/42/EC) 77
Guaranteed Sound Power Level – dB(A)
(2000/14/EC, 2005/88/EC) 96
